Features&Benefits
The Tiger-Tuff is the original maximum duty elevator bucket, designed and engineered to increase bucket life and reduce breakage. This will reduce down time and lower maintenance costs. The Tiger-Tuff bucket has the thickest lip, back wall and corners to extend the life of the bucket. Standard spacing is nominal projection + 2″. The most common applications include grain, fertilizers, pellets, corn, wheat, soybeans and other agricultural and light industrial applications. This is the best bucket for high volume applications. The belt width for a single row of buckets is actual bucket width plus 2″.
FEATURES
- Thicker corners
- Thicker walls, heavy front lip for digging
- More capacity
- Cleaner discharge
- High impact and abrasion resistant
- Non-corrosive, non-sparking
BENEFITS
- Increases elevator capacity
- Lowers elevator maintenance
- Extends bucket life
- Decreases elevator down-time
- Corrosion resistant
Size Chart
MOUNTING HOLES AND VENTING TO YOUR SPECIFICATIONS
| Bucket Size, Inches | Punching, Inches | Weight, Lbs. | Capacity, Cu. Inches | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size | Length (L) | Proj. (P) | Depth (D) | Backwall Thickness | Centers (E) | # Of Holes | Bolt Size | Top Down | Polyethylene | Nylon | Urethane | Water Level (X-X) | Useable 5° Over X-5° | Std. Spacing |
| 6×5 | 6 5/8 | 5 3/4 | 5 | 0.33 | 4 3/8 | 2 | 1/4 | 1 5/8 | 0.94 | 1.08 | 1.18 | 67.20 | 73.98 | 7 |
| 7×5 | 7 5/8 | 5 3/4 | 5 | 0.33 | 2 11/16 | 3 | 1/4 | 1 5/8 | 1.10 | 1.26 | 1.38 | 79.72 | 89.24 | 7 |
| 8×5 | 8 5/8 | 5 3/4 | 5 | 0.33 | 3 1/16 | 3 | 1/4 | 1 5/8 | 1.25 | 1.44 | 1.57 | 88.54 | 97.98 | 7 |
| 9×5 | 9 5/8 | 5 3/4 | 5 | 0.33 | 3 5/8 | 3 | 1/4 | 1 5/8 | 1.41 | 1.60 | 1.77 | 107.37 | 121.27 | 7 |
| 10×5 | 10 5/8 | 5 3/4 | 5 | 0.33 | 4 1/8 | 3 | 1/4 | 1 5/8 | 1.57 | 1.80 | 1.97 | 121.30 | 138.89 | 7 |
| 11×5 | 11 5/8 | 5 3/4 | 5 | 0.33 | 3 | 4 | 1/4 | 1 5/8 | 1.72 | 1.98 | 2.16 | 140.70 | 153.16 | 7 |
| 12×5 | 12 5/8 | 5 3/4 | 5 | 0.33 | 3 3/8 | 4 | 1/4 | 1 5/8 | 1.88 | 2.16 | 2.36 | 159.87 | 167.14 | 7 |
| 8×6 | 8 5/8 | 6 7/8 | 6 | 0.40 | 3 1/16 | 3 | 1/4 | 1 5/8 | 1.82 | 2.09 | 2.28 | 135.56 | 150.85 | 8 |
| 9×6 | 9 5/8 | 6 7/8 | 6 | 0.40 | 3 5/8 | 3 | 1/4 | 1 5/8 | 1.97 | 2.26 | 2.47 | 150.26 | 165.87 | 8 |
| 10×6 | 10 5/8 | 6 7/8 | 6 | 0.40 | 4 1/8 | 3 | 1/4 | 1 5/8 | 2.13 | 2.40 | 2.67 | 170.69 | 185.62 | 8 |
| 11×6 | 11 5/8 | 6 7/8 | 6 | 0.40 | 3 | 4 | 1/4 | 1 5/8 | 2.29 | 2.63 | 2.87 | 185.18 | 200.36 | 8 |
| 12×6 | 12 5/8 | 6 7/8 | 6 | 0.40 | 3 3/8 | 4 | 1/4 | 1 5/8 | 2.44 | 2.81 | 3.05 | 200.37 | 220.58 | 8 |
| 13×6 | 13 5/8 | 6 7/8 | 6 | 0.40 | 3 5/8 | 4 | 1/4 | 1 5/8 | 2.60 | 2.99 | 3.25 | 220.78 | 240.48 | 8 |
| 12×7 | 12 7/8 | 7 7/8 | 7 | 0.42 | 3 3/8 | 4 | 5/16 | 2 | 3.60 | 4.00 | 4.85 | 269.24 | 298.12 | 9 |
| 13×7 | 13 7/8 | 7 7/8 | 7 | 0.42 | 3 5/8 | 4 | 5/16 | 2 | 3.86 | 4.44 | 5.50 | 292.51 | 323.22 | 9 |
| 14×7 | 14 7/8 | 7 7/8 | 7 | 0.42 | 3 | 5 | 5/16 | 2 | 4.14 | 4.75 | 5.75 | 315.77 | 350.58 | 9 |
| 15×7 | 15 7/8 | 7 7/8 | 7 | 0.42 | 3 1/4 | 5 | 5/16 | 2 | 4.47 | 5.00 | 5.85 | 346.64 | 383.38 | 9 |
| 16×7 | 16 7/8 | 7 7/8 | 7 | 0.42 | 2 7/8 | 6 | 5/16 | 2 | 4.68 | 5.50 | 5.95 | 377.41 | 415.14 | 9 |
| 11×8 | 11 7/8 | 8 7/8 | 8 1/4 | 0.50 | 3 | 4 | 5/16 | 2 | 4.45 | 5.16 | 6.02 | 340.02 | 374.70 | 10 |
| 12×8 | 12 7/8 | 8 7/8 | 8 1/4 | 0.50 | 3 3/8 | 4 | 5/16 | 2 | 4.71 | 5.10 | 5.95 | 373.00 | 411.05 | 10 |
| 13×8 | 13 7/8 | 8 7/8 | 8 1/4 | 0.50 | 3 5/8 | 4 | 5/16 | 2 | 4.92 | 5.20 | 6.30 | 404.85 | 446.15 | 10 |
| 14×8 | 14 7/8 | 8 7/8 | 8 1/4 | 0.50 | 3 | 5 | 5/16 | 2 | 5.30 | 5.40 | 6.55 | 436.80 | 481.35 | 10 |
| 16×8 | 17 | 9 1/4 | 8 1/4 | 0.50 | 2 7/8 | 6 | 5/16 | 2 1/2 | 5.35 | 6.25 | 7.40 | 512.57 | 566.39 | 10 |
| 18×8 | 19 | 9 1/4 | 8 1/4 | 0.50 | 3 1/8 | 6 | 5/16 | 2 1/2 | 5.89 | 6.95 | 8.08 | 567.49 | 627.08 | 10 |
| 20×8 | 21 | 9 1/4 | 8 1/4 | 0.5 | 3 1/2 | 6 | 5/16 | 2 1/2 | 6.62 | 7.40 | 8.80 | 646.81 | 714.73 | 10 |
| 22×8 | 23 | 9 1/4 | 8 1/4 | 0.50 | 4 | 6 | 5/16 | 2 1/2 | 7.85 | 9.00 | 11.02 | 701.90 | 757.40 | 10 |
| 24×8 | 25 | 9 1/4 | 8 1/4 | 0.50 | 3 1/2 | 7 | 5/16 | 2 1/2 | 8.50 | 10.15 | 11.75 | 763.40 | 831.08 | 10 |
| 16×10 | 17 | 11 1/4 | 10 | 0.75 | 2 7/8 | 6 | 5/16 | 2 1/2 | 8.87 | 10.75 | 12.24 | 795.70 | 875.37 | 12 |
| 18×10 | 19 | 11 1/4 | 10 | 0.75 | 3 1/8 | 6 | 5/16 | 2 1/2 | 9.83 | 11.20 | 13.45 | 910.00 | 1001.21 | 12 |
| 20×10 | 21 | 11 1/4 | 10 | 0.75 | 3 1/2 | 6 | 5/16 | 2 1/2 | 10.57 | 11.95 | 14.20 | 1032.50 | 1135.98 | 12 |
| New Sizes (Available Winter 2011/Spring 2012) | Enhanced Designs | Original Designs |
** Actual dimensions may vary slightly on all elevator buckets, depending on specified raw material.
Available Materials
| Materials | Polyethylene | Nylon | Urethane | FDA Nylon |
|---|---|---|---|---|
| Color |  Orange |
 Tan |
 Green |
 White |
| Application | Grain & Food Products | Hot, high impact, abrasive dense products | Heavy abrasion, sticky materials | Hot, high impact, abrasive food grade products |
| Temperature Range | -120°F to +180°F (210°F intermittent) |
-60°F to +300°F (350°F intermittent) |
-60°F to +180°F (210°F intermittent) |
-60°F to + 300°F |
| FDA Approved Material | Yes | No | Yes | Yes |
| Comments | Economical, high density polyethylene. FDA approved material for handling food grade products. | Best for high heat applications, with tough impact and abrasion needs. | Most flexible and abrasion resistant. Resists product sticking and sharp cutting particles. | Best for high heat food grade applications, with tough impact and abrasion needs. |
® The color orange, as applied to buckets, is a registered trademark of Maxi-Lift, Inc.
